With the easy-to-set push pin style levers, these time switches allow for basic control of electric water heaters. These time switches offer a minimum on/off time of 30 minutes, and are available for 208-250 VAC applications. With the proven reliability of our mechanical line, these time switches provide dependable electric water heater control.

• Brand Name: Intermatic
• Indoor or Outdoor: Indoor
• Product Type: Electric Water Heater Timer
• Volts: 250 V
• Color: Gray
• Packaging Type: Boxed
• Programmable: Yes
• Number in Package: 1 pk
• Cycles: 24 min
• UL Listed: Yes
• Warranty: 1 year
• Depth: 3.25 in.
• Operating Temperature: -40 -130 deg F
• Resistive Load Ratings Ranges: 21 A Max, 208-250 VAC, 60 Hz
• Width: 5.25 in.
• Knockout Dimensions Bottom: (2) Combination 1/2 in. - 3/4 in.
• Maximum On/Off Times: 2 hr
• Minimum On/Off Times: 30 min
• Height: 6.75 in.
• Switch Type: SPST
• Clock Motor Voltage: 208-250 VAC, 60 Hz
• Watts Resistive: 6250
• Wire Size Maximum: No.10 AWG
• Mechanism Type: Analog/Mechanical
• Wire Size Minimum: No.14 AWG
• Wiring Option: Terminals
