The 5-Series is one of the most compact utility pumps on the market. Ideal for light commercial and multi-purpose residential where water removal, transfer or circulation is required.

• Brand Name: Little Giant
• Sub Brand: 5-ASP-LL
• Horsepower: 1/6 HP
• Maximum Discharge Flow: 25 gpm
• Housing Material: Aluminum
• Pump Switch Type: Diaphragm Switch
• Powered By: AC
• Intake: Bottom Suction
• Pump Type: Hydroponic
• Product Type: Pump
• Agency Compliance: CSA and UL
• Maximum Feet of Head: 26 ft.
• Amps: 2 amps
• Volts: 115 V
• Minimum Temperature: 35 �F
• Maximum Temperature: 120 �F
• Height: 8.07 in.
• Width: 7.75 in.
• Depth: 4.29 in.
• Sump Pump Outlet Diameter: 1 in.
• Warranty: 1 year
• Motor Type: Submersible
• Phase: Single-Phase
• Cord Length: 18 ft.
• Discharge Type: Threaded - FNPT
• Discharge: 1 in.
• Impeller Material: Nylon
• Seal Material: Viton Retainer
• Top Bearing Type: Sleeve
• Frequency: 60 Hz
• Impeller Type: Semi-open
• Intake Screen Material: Nylon
• Pump Base Material: Plastic
• Stages: 1
• Bottom Bearing Type: Sleeve Bearing
• Motor Cooling: Water
• Motor Shaft End - Material: Stainless Steel
• Pump Length: 7.75 in.
• Pump Volute Material: Nylon
• Seal Type: Retainer
• Protection: IP68
• Switch Type: Automatic
